Wire Diameter 0.15 - 0.7 m/m Outside Diameter 0.9 - 6.5 m/m Max. Feeding Speed Unlimit Max. Production Speed 50m/m    68 minute/piece Control CNC Program Motor 2 Axes AC Servo Motor Voltage 220V Weight 350Kg Machine Dimensions L880×W880×H1530 m/m

Thread diameter 0.2m/m External diameter 1.0m/m – 1.5m/m Thread diameter 0.25m/m External diameter 1.2m/m – 1.6m/m Thread diameter 0.26m/m External diameter 1.2m/m – 1.6m/m Thread diameter 0.29m/m External diameter 1.5m/m – 2.0m/m Thread diameter 0.30m/m External diameter 1.5m/m – 2.0m/m Thread diameter 0.31m/m External diameter 1.5m/m – 2.0m/m Thread diameter 0.35m/m External diameter 1.8m/m – 2.3m/m Thread diameter 0.4m/m External diameter 1.5m/m – 2.0m/m Thread diameter 0.45m/m External diameter 2.5m/m – 3.0m/m Thread diameter 0.5m/m External diameter 2.7m/m – 3.5m/m Thread diameter 0.55m/m External diameter 3.0m/m – 3.5m/m Thread diameter 0.6m/m External diameter 3.2m/m – 3.5m/m Thread diameter 0.65m/m External diameter 3.5m/m – 3.8m/m Thread diameter 0.7m/m External diameter 4.00m/m – 4.5m/m * Above specifications are subject to change without notice.
